T18 low-altitude surveillance radar
ProductFeatures1.ExtendedDetectionRangeProvidesupto15kmsurveillancecapabilityformediumUAVs,helicopte
Product Features
1. Extended Detection Range
Provides up to 15 km surveillance capability for medium UAVs, helicopters, and vehicles, enabling early threat warning and response.
2. Superior Multi-Target Tracking
Simultaneously tracks over 300 airborne and ground targets, making it ideal for crowded airspace environments.
3. High Accuracy Monitoring
Achieves ≤5 m range accuracy and ≤0.4° angular accuracy for precise target positioning.
4. Fast Refresh & Maneuver Detection
Supports refresh rates down to 1 second and tracks targets moving up to 150 m/s.
5. Low False Alarm Rate
Advanced adaptive clutter suppression technology improves detection reliability in complex environments.
6. Easy Integration
Gigabit Ethernet interface supports integration with EO/IR cameras, command systems, and counter-UAV platforms.
Product Specifications
| Parameter | Specification |
| Frequency Band | X-Band |
| Detection Range | 15 km |
| Azimuth Coverage | 360° |
| Elevation Coverage | -4° to 60° |
| Maximum Detection Height | 2000 m |
| Blind Spot | 50 m |
| Small UAV Detection | ≥8 km (RCS 0.01㎡) |
| Medium Fixed-Wing UAV Detection | ≥15 km (RCS 1㎡) |
| Personnel Detection | ≥14 km |
| Helicopter / Vehicle Detection | ≥15 km |
| Range Accuracy | ≤5 m RMS |
| Azimuth Accuracy | ≤0.4° RMS |
| Elevation Accuracy | ≤0.4° RMS |
| Simultaneous Targets | ≥300 |
| Tracking Speed | 1–150 m/s |
| Refresh Rate | 1s / 2s / 3s |
| Communication Interface | Gigabit Ethernet |
| Power Supply | DC36–52V |
| Power Consumption | ≤330 W |
| Operating Temperature | -40°C to +55°C |
| Humidity | ≤90% |
| Protection Rating | IP66 (Host IP67) |
| Host Weight | 18.5 kg |
Application Areas
Counter-UAV and anti-drone defense systems
Airport bird detection and strike prevention
Border and coastal surveillance
Military reconnaissance and battlefield monitoring
Critical infrastructure security
Smart city low-altitude monitoring
Vehicle-mounted anti-drone platforms
Airspace management systems
24/7 unattended perimeter surveillance
Multi-sensor security networks (Radar + EO/IR)
